Underwater Connectors
Challenges relating to the marine environment are numerous as equipment goes deeper and remains in the seawater for longer periods of time. In such extreme conditions, underwater connectors have to withstand higher and higher pressure, product life cycles need to be increased and product maintenance operations simplified.
Souriau by Eaton has more than 40 years of experience in supplying robust and high-reliability marine connectors for low and high-pressure environments. Our M series subsea connectors are widely recognized as one of the most robust underwater dry mate connectors on the market.
Backshells and underwater connectors' bodies are made from a single marine bronze piece to ensure an extreme resistance to pull-out or transverse forces. Different types of cable termination are available to perfectly fit your cabling needs including overmolding (withstands pressure up to 300 bar/4350 Psi), pressure gland (withstands pressure up to 100 bar/1500 Psi), or oil filling (PBOF- withstands pressure up to 1000 bar/15000 Psi).
Derived from the M series, TP connectors (nickel-plated brass shell) offer a trade-off between high reliability and cost efficiency while the U series features 316L stainless steel components.
The 8810 series offers a premium wet mateable design withstanding pressure reaching 300 bar/4350 Psi (tested at 450 bar/6500 Psi). This is achieved by increasing creepage distances between the contacts and an innovative double lip sealing system that literally expresses water out of the connection area. No water or moisture means less corrosion of the contacts and longer connector service life when compared to other solutions.
