MIL-DTL-83513/01 & /02 Micro-D
This series is solder cup terminated featuring a metal shell. It also features gold-plated TwistPin non-removable contacts for solder termination to AWG #26 or smaller wire.
| M83513/01 & /02 Solder Cup Part Numbers | ||||
| Layout | Config. | Electroless Nickel Plated Aluminum Shell | Cadmium Plated Aluminum Shell | Passivated Stainless-Steel Shell |
| 9P | Plug | M83513/01-AN | M83513/01-AC | M83513/01-AP |
| 9S | Receptacle | M83513/02-AN | M83513/02-AC | M83513/02-AP |
| 15P | Plug | M83513/01-BN | M83513/01-BC | M83513/01-BP |
| 15S | Receptacle | M83513/02-BN | M83513/02-BC | M83513/02-BP |
| 21P | Plug | M83513/01-CN | M83513/01-CC | M83513/01-CP |
| 21S | Receptacle | M83513/02-CN | M83513/02-CC | M83513/02-CP |
| 25P | Plug | M83513/01-DN | M83513/01-DC | M83513/01-DP |
| 25S | Receptacle | M83513/02-DN | M83513/02-DC | M83513/02-DP |
| 31P | Plug | M83513/01-EN | M83513/01-EC | M83513/01-EP |
| 31S | Receptacle | M83513/02-EN | M83513/02-EC | M83513/02-EP |
| 37P | Plug | M83513/01-FN | M83513/01-FC | M83513/01-FP |
| 37S | Receptacle | M83513/02-FN | M83513/02-FC | M83513/02-FP |
| 51P | Plug | M83513/01-GN | M83513/01-GC | M83513/01-GP |
| 51S | Receptacle | M83513/02-GN | M83513/02-GC | M83513/02-GP |
| 100P | Plug | M83513/01-HN | M83513/01-HC | M83513/01-HP |
| 100S | Receptacle | M83513/02-HN | M83513/02-HC | M83513/02-HP |
